Comprehensive and Detailed Step-by-Step Explanation:

1. Understanding the AS-Path Filter:

The as-path-filter command is used in BGP to filter routes based on the AS_PATH attribute.

In this configuration:

The filter si is defined with the regular expression _65500$.

The _65500$ expression specifies that the AS_PATH must end with 65500, meaning that the route's last hop must have passed through AS 65500.

2. Option Analysis:

Option A: It accepts only the routes whose AS_Path contains AS 65500.

Incorrect.

The _65500$ filter specifically matches routes where AS 65500 is the last AS in the AS_PATH. A route may contain AS 65500 somewhere in the middle of the AS_PATH but will not match this filter unless it is the last AS.

Option B: It accepts only the routes originated from AS 65500.

Incorrect.

Routes that originate from AS 65500 have an AS_PATH that starts with 65500. However, the filter _65500$ only matches routes where AS 65500 is the last AS, not the first AS.

Option C: It accepts only the routes that last pass through AS 65500.

Correct.

The _65500$ filter ensures that the AS_PATH ends with 65500. This means that the route must have last passed through AS 65500 before being received by the local BGP router.

Option D: It accepts only the routes forwarded by AS 65500.

Incorrect.

While AS 65500 may forward the route, this is not what the filter _65500$ specifically checks for. It only ensures that AS 65500 is the last AS in the AS_PATH.

3. Summary:

The as-path-filter with _65500$ accepts only the routes where AS 65500 is the last AS in the AS_PATH.

 ACL Matching in Huawei Routers:

Access Control Lists (ACLs) are used to filter packets based on specific criteria, such as source/destination IP, ports, or protocols.

When a packet arrives, the Huawei router processes it against the configured ACL rules to decide whether to permit or deny the packet.

When the router ID is configured in both the system view and the BGP view, the router ID in the BGP view takes precedence because BGP-specific configurations override global settings. This ensures that BGP operates with the most relevant configurations ​.

 R1 is a Level-1 router in Area 49.0001, while R4 is in Area 49.0004. Level-1 routers only maintain LSDBs for their own area and do not contain LSPs from other areas, such as R4’s LSP.

 R2 is a Level-1-2 router, so it maintains LSDBs for both Area 49.0001 (Level-1) and Level-2 domains, which include LSPs from R4.

 R3 and R4, as Level-2 routers, exchange LSPs with each other within the Level-2 domain.

 Thus, the LSDB of R1 does not include R4’s LSP ​.

Explanation of VLAN Pool Assignment Algorithms:

In WLANs, VLAN pools help reduce broadcast domains and improve network performance by distributing users across multiple VLANs. Two algorithms are used for VLAN assignment:

Even Assignment Algorithm:

The number of users in each VLAN is even.

This algorithm assigns users evenly across VLANs, ensuring a balanced distribution of users in each VLAN.

When STAs go offline and online again, their VLANs and IP addresses may easily change.

Since the assignment is based on maintaining even distribution, a device (STA) may not be assigned the same VLAN when it reconnects, leading to potential IP address changes.

Hash Assignment Algorithm:

The number of users in each VLAN is uneven.

The hash algorithm assigns users to VLANs based on a hash value (e.g., derived from the MAC address). This may result in an uneven distribution of users across VLANs.

VLANs and IP addresses remain unchanged for STAs that go offline and online again.

The hash algorithm ensures that a device reconnects to the same VLAN, preserving its IP address.

A screenshot of a computer Description automatically generated

In BGP, the AS-Path attribute is mandatory and must be included in all UPDATE messages. It records the autonomous systems a route has traversed. Attributes like Local-Preference, MED, and Prefval are optional and may not always be included. The AS-Path is crucial for loop prevention and route selection ​.

Comprehensive and Detailed Step-by-Step Explanation:

WAN Definition:

A WAN is a large-scale network spanning a wide geographical area, connecting smaller networks such as LANs and MANs.

Use Cases:

WANs are commonly used for interconnecting campus networks, branch offices, and data centers over long distances.

Correct Statement:

The statement accurately describes the purpose and scope of WANs.

References:

HCIA-Datacom Study Guide, Chapter: WAN Fundamentals

Huawei Networking Basics

 OSPF Area Design and Loop Prevention:OSPF uses a hierarchical structure with areas to improve scalability and efficiency. Area 0, the backbone area, plays a crucial role in ensuring loop-free route distribution between areas. The following mechanisms are key to preventing routing loops:

Strict adherence to hierarchical area design.

Prohibition of direct inter-area route exchanges between non-backbone areas.

The CAPWAP heartbeat detection interval is typically multiplied by a predefined factor to determine the switchover time. For instance, in Huawei devices, a common default is three missed heartbeats before a switchover is triggered. With a detection interval of 20 seconds, the switchover occurs after 60 seconds (20 x 3). This ensures that transient network issues do not cause unnecessary switchovers ​.

The default sending interval for BFD (Bidirectional Forwarding Detection) control packets is 100 milliseconds. This interval ensures rapid detection of link faults, providing fast failover and minimizing downtime in network operations ​.
