Detailed Explanation:OSPF (Open Shortest Path First) has several key advantages:

It can load balance traffic among equal-cost routes.

OSPF supports hierarchical area structures, allowing for network scalability and reduced routing table sizes.

OSPF supports strong security measures through packet authentication (MD5 or plain text).

It supports Classless Inter-Domain Routing (CIDR), allowing for more efficient IP address allocation and route aggregation.

Comprehensive Explanation: The command dot1q termination vid 100 in the configuration specifies that the sub-interface is configured to receive tagged data frames for VLAN 100. VLAN tagging ensures that frames are properly identified and routed through the correct VLAN, and the sub-interface is associated with a specific VLAN ID to handle the tagged traffic.

In Huawei devices, advanced ACLs use a number range from 3000 to 3999. These ACLs allow more granular control over traffic by permitting conditions based on source and destination IP addresses, protocol types, and ports, making them suitable for complex filtering requirements​.

The PVID (Port VLAN ID) specifies the default VLAN for untagged frames.

The command port trunk pvid vlan 10 means that VLAN 10 is the default VLAN.

When untagged frames arrive, they are assigned to VLAN 10.

When the switch forwards frames from VLAN 10, it removes the VLAN tag.

VLANs 20, 30, and 40 remain tagged.

Thus, the correct answer is D (VLAN 10).

In the IP header at the network layer, the Protocol field specifies the transport layer protocol in use. The protocol number for UDP is 17, not 6. Protocol number 6 is reserved for TCP. This field allows IP packets to be correctly processed by the appropriate transport-layer protocol at the receiving device​.

Detailed Explanation:The EUI-64 format splits a MAC address into two parts and inserts "FFFE" in the middle. The Universal/Local (U/L) bit is flipped, so a valid EUI-64 address would be 02E0-FCEF-FFFE-0FEC​.

Detailed Explanation:In a "one-armed routing" setup, a router with sub-interfaces can handle inter-VLAN routing by logically segmenting traffic within a single physical interface. In this configuration, each department (Administration and Finance) is assigned a different VLAN with separate sub-interfaces on Router R1.

In such a setup, communication between different VLANs (i.e., inter-VLAN routing) is handled by the router, even without Proxy ARP enabled. The router can directly route packets between the VLANs as it is aware of the different networks and performs Layer 3 forwarding based on the IP address of each VLAN's sub-interface.

Thus, even if ARP Proxy is disabled, devices in the Administration and Finance departments can communicate through the router because inter-VLAN routing takes place at Layer 3 without relying on ARP proxy functionality​​​.

DHCP (Dynamic Host Configuration Protocol) can allocate various network parameters, including:

IP address: Assigns a unique IP to each client.

Gateway address: Provides the default gateway for routing traffic.

DNS server address: Allows domain name resolution. The DHCP server does not assign an operating system, as this is outside its scope​.

Error Analysis:The error message indicates that the command entered is not recognized by the device. This typically occurs when the syntax is incorrect or the first keyword of the command is unrecognized. The system identifies the problem location ('A' position), which points to the initial part of the command.

Analysis of Options:

Option A: "The entered parameter is not specified" refers to cases where a valid command is incomplete due to missing parameters, not an unrecognized command. This is unrelated to the error displayed.

Option B: "The entered command is incomplete" applies when additional parameters are needed to complete the command. However, the system explicitly states "unrecognized command," ruling this out.

Option C: "The parameter type is incorrect" refers to an error where a parameter is of the wrong type (e.g., string instead of integer). This is not related to keyword recognition.

Option D: "No keyword is found" directly aligns with the error message, as the system cannot recognize the first keyword of the command, making it the correct answer​​.
