350-501 Exam Dumps - Cisco CCNP Service Provider Questions and Answers

To ensure that critical, time-sensitive data from the server on R1 to the host on R3 is always prioritized, especially during congestion, the network engineer should implement a Quality of Service (QoS) strategy that uses strict priority queuing. This QoS mechanism ensures that traffic marked as high priority is transmitted first, while other traffic may be queued or dropped if necessary. Strict priority queuing is designed for scenarios exactly like this, where certain traffic must be guaranteed bandwidth to meet time-sensitive requirements. References := For more detailed information on QoS strategies and classification, refer to the Implementing and Operating Cisco Service Provider Network Core Technologies (SPCOR) course materials, specifically the sections discussing QoS mechanisms and their implementation in service provider networks. Additionally, Cisco’s official documentation on QoS provides comprehensive guidelines on configuring and applying strict priority queuing to ensure bandwidth for critical traffic.

 The configuration shown in the exhibit indicates a BGP FlowSpec policy that is configured locally on CSR1. This policy is designed to drop all traffic destined for TCP ports 80 and 443 for the IP address 10.6.5.0/24. The traffic rate is displayed as 0 bps, which suggests that the policy is not currently dropping any traffic. However, the matched and dropped statistics indicate that the policy has been active in the past, as it has matched and dropped packets.

References: This explanation is based on the principles of BGP FlowSpec configuration and operation as outlined in the Implementing and Operating Cisco Service Provider Network Core Technologies (SPCOR) study materials.

IOS XE:

It uses linux-based kernel

It has a separate control plane

IOS:

It is monolithic

It shares memory space

In the context of OSPF multiarea implementation, adjacency issues can often be resolved by specifying the type of network on the interface. In this case, option B “ip ospf network point-to-point” is appropriate as it helps in forming OSPF adjacency over point-to-point links by allowing OSPF to use a simpler neighbor discovery process, which can resolve adjacency issues. References := Implementing and Operating Cisco Service Provider Network Core Technologies

 The iosxr_command module in Ansible is used to issue commands on remote devices running Cisco IOS XR. This module allows network administrators to execute operational commands on Cisco routers and switches, which is essential for tasks such as retrieving information or applying configuration changes. It is a part of network automation using Ansible, which simplifies the management of network devices by automating repetitive tasks.

References: Implementing and Operating Cisco Service Provider Network Core Technologies (SPCOR) course and study guide

The command PE-A(config-pmap-c)#set dscp ef is used to apply DSCP marking to the traffic matched by the class-map. DSCP marking is a part of QoS policy to prioritize traffic. The ‘ef’ (Expedited Forwarding) value is commonly used for voice traffic to ensure it receives high priority and low delay through the network.

References: For more information, refer to the QoS section in the Implementing and Operating Cisco Service Provider Network Core Technologies (SPCOR) course materials.

In the given architecture, if each area is running its own Interior Gateway Protocol (IGP), Border Gateway Protocol (BGP) must be used to provide an end-to-end Multiprotocol Label Switching (MPLS) Label Switched Path (LSP). This ensures that data packets can traverse through the different IGP areas seamlessly, maintaining connectivity across the entire network.

Packet loops can occur during the configuration of BIDIR-PIM if not all parts of your network support this protocol or are configured correctly for it. If some routers or switches in your network don’t understand or aren’t configured for BIDIR-PIM, they can inadvertently forward packets back into parts of the network they were already in, creating a loop. References: Implementing and Operating Cisco Service Provider Network Core Technologies (SPCOR) - Multicast section.
