SRX chassis clustering is a high availability feature that allows two SRX Series devices to operate as a single logical device. The two devices are connected by a control link and a fabric link, which are used to synchronize the configuration, state, and traffic between the nodes. The control plane is responsible for managing the cluster configuration, monitoring the health and status of the nodes, and performing failover operations. The data plane is responsible for processing and forwarding the traffic through the cluster. SRX chassis clustering supports two modes for the data plane: active/passive and active/active. In active/passive mode, only one node is active for each redundancy group, which is a logical grouping of interfaces and services. The active node handles all the traffic for the redundancy group, while the passive node acts as a backup. In active/active mode, both nodes are active for different redundancy groups, and they can share the traffic load for the cluster. SRX chassis clustering supports only one mode for the control plane: active/passive. In this mode, only one node is the primary node, which is the master of the cluster configuration and the source of truth for the cluster state. The primary node also initiates the failover process in case of a node or interface failure. The other node is the secondary node, which is the slave of the cluster configuration and the backup of the cluster state. The secondary node takes over the primary role if the primary node fails or is manually disabled. References: Chassis Cluster Overview, SRX Series Chassis Cluster Configuration Overview, Chassis Cluster Overview

Security policy schedulers are a feature that allows you to activate or deactivate a policy for a specified time period. You can create schedulers for a single or recurrent time slot, and apply them to one or more policies. A policy can only have one scheduler associated with it, but a scheduler can have multiple policies associated with it. When a scheduler is active, the policy is available for policy lookup. When a scheduler is inactive, the policy is unavailable for policy lookup. A policy without a defined scheduler will always be active, unless it is explicitly disabled. References:

• Scheduling Security Policies
• schedulers (Security Policies)
• Security Policy Schedulers
• scheduler (Security Policies)

A reth LAG is a redundant Ethernet interface that includes one or more physical interfaces from each node of a chassis cluster. A reth LAG provides increased bandwidth and link availability for the cluster. To configure a reth LAG, you need to follow these steps:

• Configure the physical interfaces on each node as aggregated Ethernet interfaces with the same speed and duplex settings. This is required to ensure that the links can form a LAG andpass traffic correctly. You can use different cable types (such as copper or fiber-optic) for the links, but the speed must be the same.
• Configure the reth interface with the redundant-ether-options statement and specify the aggregated Ethernet interfaces as child links. You should have at least two interfaces (one from each node) in the reth LAG, but you can add more for redundancy and load balancing. You can also specify the minimum-links statement to set the minimum number of child links that must be up for the reth interface to be up. The default value is one, but you can change it to a higher value if needed.
• Configure the reth interface with the appropriate IP address, security zone, and other settings as needed. You can also enable LACP on the reth interface to dynamically negotiate the LAG parameters with the peer devices.

References:

• [Aggregated Ethernet Interfaces in a Chassis Cluster] 1
• [Chassis Cluster Redundant Ethernet Interfaces] 2
• [LACP / LAG on Chassis Cluster - Interface Monitoring?] 3
• [URGENT (LAG - RETH Interconnect)] 4
